How to Change an HPLC Pump Seal | Shimadzu LC-20AD

How to Change an HPLC Pump Seal | Shimadzu LC-20AD

Hello, lab warriors! Today, we're tackling a task that can strike fear into the hearts of even the most seasoned scientists - changing the pump seal on a Shimadzu LC-20AD HPLC. But fear not! By the end of this post, you'll be swapping out seals like a pro. So, strap on your safety goggles, pull on your lab gloves, and let's dive in!

Step 1: Disconnecting the Fittings ūüĒß

Our journey begins with a simple twist and turn. We're disconnecting the fittings on the pump. It's like untying your shoelaces before you take off your shoes - a small step, but a necessary one.

Why it matters: This step is crucial because it allows us to access the pump head, where the seal resides. If you skip this step, you'll be trying to change a seal on a sealed pump - a task as impossible as trying to eat soup with a fork!

Step 2: Removing the Pump Head ūüé©

Next, we're removing the pump head. This step requires an Allen wrench and a gentle touch. Remember, we're scientists, not barbarians!

Why it matters: The pump head is the home of the seal. If you skip this step, you'll be trying to change a seal that you can't even reach - like trying to change a lightbulb without removing the lampshade!

Step 3: Removing the Seal ūüöę

Now, it's time to remove the old seal. This step requires a special tool and a bit of elbow grease. But don't worry, you've got this!

Why it matters: The old seal is the reason we're here. If you skip this step, you'll be trying to install a new seal on top of the old one - like trying to wear a new pair of socks without taking off the old ones!

Step 4: Installing the New Seal ‚úÖ

We're on the home stretch now, folks! It's time to install the new seal. Remember, the seal should be pre-soaked in IPA. It's like marinating a steak before you grill it - it makes everything better!

Why it matters: The new seal is the star of the show. If you skip this step, you'll have a pump without a seal - like a car without an engine!

Step 5: Reinstalling the Pump Head ūüé©

We're almost there! Now, we're reinstalling the pump head. Remember, place it straight to avoid damaging the new seal. It's like putting a hat on straight - it just looks better!

Why it matters: Reinstalling the pump head protects the new seal. If you skip this step, your new seal will be exposed to the elements - like leaving a new car out in the rain!

Step 6: Reconnecting the Fittings ūüĒß

Congratulations, you've made it to the final step! We're reconnecting the fittings. It's like tying your shoelaces after you've put on your shoes - the final touch on a job well done.

Why it matters: Reconnecting the fittings ensures your pump is ready to go. If you skip this step, your pump will be as useful as a car without wheels!

And there you have it, folks! You've successfully changed the pump seal on a Shimadzu LC-20AD HPLC. Give yourself a pat on the back, you've earned it! Remember, every great scientist started as a beginner. So keep learning, keep experimenting, and who knows? Maybe one day, you'll be a lab legend! ūüéďūüĒ¨

Disclaimer: No lab warriors were harmed in the making of this blog post.
